CabKing-8V1. Complete with Wheels/Water. Plenty of Room

In Stock
$4,350.00

3 units in stock



Calculate Shipping

The CabKing 8V1: A complete 8” diamond grinding/polishing machine. For the serious Cabber, Gem Club or Gem Shop.

At last a 6 wheel x 8" cabber with lots of space between the Wheels.

NB: these are Large to ship - contact us so we can quote you the best freight price. They are packed well in two large cartons and one small so freight is important to get right.   Please ask for a Freight quote!

These are BIG cabbing machines - well built with great features. A great addition to the extremely popular 6" version - this one is a 8"complete kit for the serious cabber (see photos below). Aussie Sapphire is proud to be the Exclusive Australian Dealers for Cabking.

For more information, click the PDF icon to download the User Guide.


The CABKING-8V1 is a rugged, professional grade 8” diameter diamond wheel grinding and polishing machine for all your cabbing needs. One of the main elements of this machine is the water cooling system. The CABKING-8V1 has an adjustable, independently controlled drip feed cooling system that drips clean water on the wheels instead of bubbling up dirty water. This system is based on a separate water pump that eliminates costly upkeep of the built in air pump found on other machines. The water system allows for individual cooling of the wheels and water flow can be controlled from a drip to a stream,it uses Fresh water only no recycling that causes Contamination. . Our simplified drainage system has a hose connected to the rust-free pans so you can drain the dirty pan water without having to constantly pour it out. The advanced cooling system is just one of the many features found in the CABKING-8V1.

A direct drive motor and separate submersible pump to reduce maintenance. Individual on/off water shut off valves above each wheel, also for right and left hand grinding/polishing pads (no cross-contamination of grit) allows easy of movement from wheel to wheel to disc. A drainage system to eliminate having a constantly discard pan water. Heavy-duty base board, aluminum splash hoods with adjustable clear splash shields, plastic pad with drain holes, comes with four side splash guards, and two front hand metal rests.

Package includes:
  • Plastic apron and clear plastic goggles
  • Complete instructions for machine assembly and use.
  • Two x  8” x 1-1/2” metal bonded diamond grinding wheels:  #80 and #220,
  • Four x  8” x 2” diamond resin bond wheels:  (1) each #280, #600, #1200, and #3000
  • One  x 8” #360 no hole 1/4-20 right hand threaded diamond flat lap
  • One x  5-1/2” 1/4-20 right hand canvas polishing pad with 2 grams of syringe of 14,000 diamond paste compound.

Driven with a powerful 3/4 hp, single phase, new version now in 230 Volt to suit the Australian power supply - just plug in and go, 1800 rpm, stainless steel removable hoods, 30 watt/605 GPH, 220 volt water pump. With a 6 watt, 12 volt, single bayonet lamp.

Overall size is 42” long x 15.5” deep x 12” high.

Normal Aussie Sapphire One year warranty - all carried out by us in Australia.
We carry a full range of spares in stock for these units.

(395)

SKU 395
Brand CabKing
Shipping Weight 75.0000kg
